StreamTensor: A PyTorch-to-Accelerator Compiler that Streams LLM Intermediates Across FPGA Dataflows

Why treat LLM inference as batched kernels to DRAM when a dataflow compiler can pipe tiles through on-chip FIFOs and stream converters?StreamTensor is a compiler that lowers PyTorch LLM graphs (GPT-2, Llama, Qwen, Gemma) into stream-scheduled dataflow accelerators on AMD’s Alveo U55C FPGA. The system introduces an iterative tensor (“itensor”) type to encode tile/order of streams, enabling provably correct inter-kernel streaming and automated insertion/sizing of DMA engines, FIFOs, and layout converters. On LLM decoding workloads, the research team reports up to 0.64× lower latency vs. GPUs and up to 1.99× higher energy efficiency.

What StreamTensor does?

StreamTensor compiles PyTorch graphs into a stream-oriented dataflow design so that intermediate tiles are largely avoids off-chip DRAM round-trips via on-chip streaming and fusion; DMAs are inserted only when required; they are forwarded through on-chip FIFOs to downstream kernels. The compiler’s central abstraction—iterative tensors (itensors)—records iteration order, tiling, and layout, which makes inter-kernel stream compatibility explicit and drives converter generation only where needed. The framework also searches hierarchically over tiling, fusion, and resource allocation, and uses a linear program to size FIFOs to avoid stalls or deadlock while minimizing on-chip memory.

What’s actually new?

• Hierarchical DSE. The compiler explores three design spaces—(i) tiling/unroll/vectorization/permutation at the Linalg level, (ii) fusion under memory/resource constraints, and (iii) resource allocation/stream widths—optimizing for sustained throughput under bandwidth limits.
• End-to-end PyTorch → device flow. Models enter via Torch-MLIR, are transformed to MLIR Linalg, and then into a dataflow IR whose nodes become hardware kernels with explicit streams and host/runtime glue—no manual RTL assembly.
• iterative tensor (itensor) typing system. A first-class tensor type expresses iteration order, tiling, and affine maps. This makes stream order explicit, allows safe kernel fusion, and lets the compiler synthesize minimal buffer/format converters when producers/consumers disagree.
• Formal FIFO sizing. Inter-kernel buffering is solved with a linear-programming formulation to avoid stalls/deadlocks while minimizing on-chip memory usage (BRAM/URAM).

Results

Latency: up to 0.76× vs prior FPGA LLM accelerators and 0.64× vs a GPU baseline on GPT-2; Energy efficiency: up to 1.99× vs A100 on emerging LLMs (model-dependent). Platform context: Alveo U55C (HBM2 16 GB, 460 GB/s, PCIe Gen3×16 or dual Gen4×8, 2×QSFP28).

The useful contribution here is a PyTorch→Torch-MLIR→dataflow compiler that emits stream-scheduled kernels and a host/runtime for AMD’s Alveo U55C; the iterative tensor type plus linear-programming-based FIFO sizing enables safe inter-kernel streaming rather than DRAM round-trips. On reported LLM decoding benchmarks across GPT-2, Llama, Qwen, and Gemma, the research team show geometric-mean latency as low as 0.64× vs. a GPU baseline and energy efficiency up to 1.99×, with scope limited to decoding workloads. The hardware context is clear: Alveo U55C provides 16 GB HBM2 at 460 GB/s with dual QSFP28 and PCIe Gen3×16 or dual Gen4×8, which aligns with the streaming dataflow design.
